Malaysia’s JB Cocoa enhances its Indonesian processing operations
Malaysian-based business JB Cocoa, based in Jahor, has reported an upturn in the efficiency of its processing, as it reveals in this insight into its operations within the region, which includes a facility in Indonesia.
Starting out in the 1980s, JB Foods began as a processor of wet cocoa beans to dry cocoa beans in the 1980s. As the business explained, it has now grown into an enterprise with a total processing capacity of 180,000 metric tonnes of cocoa beans equivalent per year. The international group’s principal activities comprise the production and sale of cocoa ingredient products, namely cocoa butter, cocoa powder and cocoa mass under its JB Cocoa branding.
From locally grown cocoa beans, the company’s Indonesian facilities, located 30 km from the port of Surabaya (pictured) in the province of East Java, can process 50,000 tonnes of cocoa beans annually.
The beans are cleaned, roasted and winnowed to separate the cocoa nibs, which are treated to enhance flavour and colour. The nibs are then ground into cocoa liquor, which is squeezed by a “butter press” to yield cocoa butter used in making chocolate, and crumbled cocoa “presscake” that is pulverised into cocoa powder.
A portion of the presscake is shipped directly to customers in 1 tonne bulk bags, but most is processed into cocoa powder and packaged in handheld sacks.
Rapid discharging from bulk bags dust-free
To increase efficiency of the cocoa powder line, the plant installed a Flexicon bulk-out BFC-C-X bulk bag discharger to handle loose cocoa presscake being put in storage before being reduced to powder and packaged for customers
The discharger is configured with an electric hoist and trolley that ride on a cantilevered I-beam, allowing bulk bags to be loaded into the frame without the need for a forklift.
To connect a bag, the operator slips the bag straps into four Z-Clip strap holders of a bag lifting frame, and uses a pendant to hoist the bag into the discharger frame. A Tele-Tube telescoping tube pneumatically raises a Spout-Lock clamp ring, allowing an operator to make a high-integrity sealed connection between the clean side of the bag spout and the clean side of the equipment.
With the bag spout secured, the operator pulls its drawstring, allowing presscake to discharge into the surge hopper.
Releasing the telescoping tube’s air pressure allows the clamp ring to maintain constant downward tension by gravity as the bag empties and elongates to promote material flow. Additional flow promotion is provided by Flow-Flexer bag activators that raise and lower opposite sides of the bag bottom to promote complete discharge through the bag spout.
The 226 l capacity surge hopper with top-mounted enclosure is vented to a side-mounted Bag-Vac dust collector that creates negative pressure within the sealed system to prevent displaced air and dust from escaping into the plant environment.
The enclosure also serves to contain spillage that might otherwise escape through seams in the bag and folds in the spout, and is equipped with a hinged access door and folding bag shelf, allowing manual dumping of under-filled sacks.
A rotary valve at the hopper outlet metres the presscake into a pneumatic conveying line that moves it to a storage silo. From there, it is mixed and milled into six different recipes of cocoa powder and packed into 25 kg bags.
Achieving plant hygiene and efficiency
Constructed of stainless steel finished to sanitary standards, the discharger is certified for operation in food-grade environments. “The use of the Flexicon bulk bag discharger provides a safe and hygienic way to unload cocoa cake from bulk bags.” said JB Cocoa’s Redi Koerniawan. “It ensures efficient unloading with little to no dust released into the processing environment.”
